Alpha Mechanical Detachable Double Drop Lowboy (A80MG)

SKU: Alpha HD 110HDG Hydraulic RGN Lowboy Categories: , ,

Alpha Mechanical Detachable Double Drop Lowboy

Model: A80MG

Capacity: 80,000 LBS

Concentrated 70,000 LBS in 16’

48’ OAL

102” OAW


10’ Mechanical Detachable

49” 5th Wheel Height

16” King Pin

84” Swing Clearance

2 Bent D-Rings Per Side

Lighning Holes Each Side of Platform

2 Position Neck Connection Plate (49”/51”)

Stainless Steel Mudflaps

Toolbox in Base of Neck with Door & Light

Air Assist Gooseneck Support Arm

Sub Frame

9’ Long

40” Loaded Deck Height

Full Width Decking

1 Pair Flag Holders

1 Pair Stake Pockets in Tail Channel

2 Pair of Chain Slots Mid Platform

1 Pair Pan D-Ring at Rear

Frame Reinforcement for Flip Axle

Main Deck

29’ Length 12” Fabricated I-Beams

18” Loaded Deck Height

6” Ground Clearance

6”/4” JR I-Beam Cross Members Alt on 12” Centers

8 Bent D-Rings Per Side

Chain Slots on 24” Centers Each Side

1 1/8” Apitong Flush Decking Full-Width

Front Ramps Tapered to 4” with Traction Bars

Removeable Swingout Outriggers on 12” Center

Axles & Suspension

2 – 25,000 LB Axles

54” Axle Spacing

Ridewell Suspension

16 ½” x 7” Drum Brakes


Spring Brakes on Both Axles

Raise & Lower Valve

Manual Ride Height Control

WTT/70R22.5 Tires

8.25 x 22.5 Aluminum Wheels Outside Steel Wheels Inside

Lighting, Safety, & Paint

2 Tail Light Package with Stainless Steel Covers

Grote Ultra Blue-Seal Wire Harness

4” Amber Strobe Light

Liquid Filled Air Gauge

Painted Black

Now Available
